Guide TU650P 3.0 Thermal Riflescope with In-Lens LRF

The Guide TU650P 3.0 is a premium thermal riflescope built around a 640 × 512 thermal sensor, an ultra-fast 50mm F0.9 lens, and a laser rangefinder built into the objective lens. With a QHD 2560 × 2560 AMOLED display, 256 GB of onboard storage, and a 14-hour battery, the TU650P is purpose-built for hunters who demand peak thermal performance without compromise.

Key Features

• 640 × 512 thermal sensor, 12 μm pixel pitch — over 327,000 thermal pixels with ≤18 mK NETD produce sharp, detailed imagery in complete darkness and through smoke, with a thermal detection range of 2,600 meters. The 50 Hz shutterless 3.0 calibration keeps the display live at all times — no freeze frames during recalibration.

• 50mm F0.9 objective lens — a faster aperture than the F1.0 lens on the TU650L and TU650M. The wider F0.9 aperture gathers more infrared energy than an F1.0 design, producing brighter images and better contrast when ambient temperature differentials are low — the exact conditions that challenge lesser thermals at dawn, dusk, or in cool-weather hunts.

• In-lens laser rangefinder (1,500 m) — Guide builds the rangefinder into the objective lens, which puts it close to the optical axis, significantly reduces parallax error and keeps the scope compact. Range targets and get holdover corrections from the ballistic calculator, set up in Guide's TargetIR Ballistics app as on the other TU 3.0 scopes.

• QHD 2560 × 2560 AMOLED display — over 6.5 million pixels, more than eight times the pixels of a 1024 × 768 display. Every pixel of sensor data is rendered with sharp clarity across the full magnification range.

• Recoil-activated recording — each shot automatically captures a 15-second video clip and 5 still photos, stored on 256 GB of internal memory. Instant playback lets you review shots without lowering the rifle.

• 14-hour battery with hot-swap 18650 cells — dual internal rechargeable batteries plus an external 18650 bay deliver 14 hours, matching the TU650M for the longest runtime in the TU series. Standard 18650 cells mean replacement batteries are available anywhere, and hot-swap capability lets you change the external cell without powering down.

• IP68 / 6,000J shock rating — fully sealed against dust and submersion, and rated for recoil up to .300 Win Mag. Built to perform in extreme cold (−4°F) through desert heat (122°F).

Comparing models? See where the TU650P fits in the full Guide Sensmart thermal range, or browse our other thermal riflescopes.

Ideal For

Dedicated thermal hunters who use thermal exclusively — the F0.9 objective and in-lens LRF deliver a pure thermal experience with no dual-channel complexity or added weight.

Long-range predator and hog hunters who need to detect, range, and engage targets at extended distances in total darkness, with holdover solutions calculated on-screen and no external rangefinder required.

Hunters who prioritize battery life on multi-day hunts or extended sits. At 14 hours of continuous runtime with hot-swappable 18650 cells, the TU650P matches the TU650M for the longest runtime in the TU series.

Professional users and outfitters who need a sealed, all-weather thermal optic with integrated LRF, ballistic calculator, and shot recording in a single package rated for the harshest conditions.
